Barcode Scanner 2D Scanner

1.2Meters Anti-shock
All 1D 2D Barcode
Screen Barcode
Fast Speed
Accurate

Send Inquiry

Chat Now

Product Introduction

Barcode Scanner 2D Scanner Performance parameter

Sensor:640'480 COMS,4P Cameralens

Scanning method:manual or automatic induction

Lighting:white LED

Focusing:red lED

Motion tolerance:2M/S

Reading precision:(>4MIL)

Scanning angle:Rotation 360°,Tilt 55°,Pitch55°

Visual Indicator:LED&buzzer

Communication Interface:USB (HID-KBW & Virtual Serial Port)

Supported Barcode:2D barcode:0R Code.Data Matrix.PDF417.Aztec.Maxicode.Hanxin Code

1D barcode:EAN,UPC.Code39.Code 93Code128UCC/EAN128Codabar Interleaved 2 of 5

HY10-XQ-2

Barcode Scanner 2D Scanner Physical parameters

SIZE:L[164]'W[65]'H(98)'MM

Weight:138G[not including the cable]

Visualindicator:Two-color LED lampabuzzer

Voltage:DC:5V Working Voltage:3.3V

Current:working current:65MA,StandbyCurrent:15MA,Maximum current:85MA

HY10-XQ-3

Barcode Scanner 2D Scanner Environmental parameters

Working temperature:-20℃+50℃

Storage temperature:-40C+70℃

Relative Humidity:5%~95%(Non-condensing)

Electrostatic Protection:4KV [DirectDischarge]10KV(Air Discharge)

Drop/Shock Resistance:withstands multiple times1.2 meters drops to concrete

Protection Level:IP54

HY10-XQ-6
