Flat Bed Die Cutting Machine

Flat Bed Die Cutting Machine

Model:CW-350FII
Delivery time: 15-20 working days
Warranty: 1 year
Package: exported wooden case
Send Inquiry
Chat Now
Product Introduction
Products Description

Functional characteristics of flat bed die cutting machine is automatic slitting machine, which is a matched machine with die cutting machine, it is suitable to slit narrow paper, it can automatic meter, set length, automatic stop, automatic web-guiding and so on functions. Whole machine is with compact structure、running fast、high efficiency、high accuracy、easy-operation、running stably etc features.

Slitting speed120m/min
Max. Width350mm
Max. Unwinding diameter500mm
Max. rewinding diameter500mm
Min. Slitting width16mm
Max. Slitting width340mm
Accuracy rate±0.10mm
Voltage220v
Main motor power1.5kw
weight500kg
Dimension1200*800*1280m m

flat bed die cutting machine of features: 1. Turret shaft, and easy to change different size of rewind shaft 2. All shafts automatic inflate air 3. This standard machine with 3 magnetic tension controllers. 4. Machine with 6 shafts, 1inch,1.5inch and 3inch shafts all can be used

20221031183346585f73c2082447369d13149d0662e786

20221031183346a519569dc4974306af07f87b93df4107

20221031183347c8ea99f54ab841b5bd96290342ed6c79

202210311833486860629c204b495997b736e9f88eb196

20221031183349b7fdb77166914bf1830909242f0239af

Hot Tags: flat bed die cutting machine, China, manufacturers, suppliers, factory, buy, wholesale, price, cheap, free sample, made in China
