Barcode Scanner 1D Laser

Barcode Scanner 1D Laser

Perlormance parameter

Lightsource: 610~630nm laserdiode

Scanning method: manual or continue scan

Barcode Sensitivity: pitch±50°tilt35°skew±55 Reading mode: trigger reading

Contrast: ≥30% Reflection Difference Scanning speed:300times/s

Supported Bar code: EAN.UPC.Code 39.Code 93.Code 128.UCC/EAN 128.Codabar,

                                  Interleaved 25 ITF-6ITF-14,ISBN.ISSN.MSI-PlesseyGS1Databar

                                  GS1Composite Code.Code11 Industrial 25,Standard 25,Plessey,

                                  Matrix25

Interface:USB&RS232

Barcode Scanner 1D Laser Physical Parameters

SIZE:L(164)'W(65)'H(98)MM

Weight:138G(not inciuding the cable)

Visual Indicator:Two-color LED lamp&buzzer

Voltage:DC:5V

Current:working current:65MA.StandbyCurrent:15MA,Maximum current:85MA

Barcode Scanner 1D Laser Environmental parameters

Working temperature:-20℃+50℃

Storage temperature:-40c+70℃

Relative Humidity:5%~95%(Non-condensing)

Electrostatic Protection:4KV[Direct Discharge]10KV(Air Discharge)

Drop/Shock Resistance:withstands multiple times 1.2 meters drops to concrete

Protection Level:IP54

Depth offield and resolution [1MI=0.0254MM)

4MIL--27-60MM

5MIL--18-130MM

10MIL--10-320MM

20MIL-19-600MM
