Codewel CW523 High-Performance Resin-Enhanced Wax Thermal Transfer Ribbon
Codewel CW523 High-Performance Resin-Enhanced Wax Thermal Transfer Ribbon
Model：CW523
Strong Scratch Resistance
High Blackness
High Efficiency
Hangzhou Codewel New Material Co.,Ltd is located at beautiful city Hangzhou and is a global thermal transfer printer&ribbon manufacturer integrated with R&D,production and marketing. Codewel is mainly engaged in the research and development of the One-Stop barcode solution. we are specializing in producing Barcode Jumbo Label, barcode stcikers, thermal transfer ribbons, hot stamping foils,and also providing thermal transfer printers,printhead,Bar code Scanner etc. All those can be widely applied in medicine, food, dairy products,clothing,electronics, electrical appliances, transportation,logistics,packaging industries etc.
Coated Paper & Hangtags: ★★★★★ (Optimal performance)
Synthetic Paper: ★★★★☆ (High durability)
PET / PP / PVC Films: ★★★☆☆ (Acceptable for standard application)
Key Features & Highlights
Resin-Enhanced Performance:
Superior scratch and smudge resistance compared to standard wax ribbons.
Low Energy & High Speed:
Exceptional dark print density even at lower heat settings and speeds up to 10 IPS.
Printhead Protection:
Patented back-coating technology effectively eliminates printing noise and protects thermal printheads.
Wide Media Adaptability:
Excellent print clarity on coated paper, synthetic paper, and films.
| Parameter | Specification | Parameter | Specification |
| Material | Premium Resin-Enhanced Wax | Ink Melting Point | 74°C |
| Color Density | ≥2.30DR | Printing Speed | 0-10IPS |
| Carrier Thickness | 4.5±0.3μm | Heat Resistance | 80°C |
| Total Thickness | 7.5±0.5μm | Storage Condition | -5°C ~ 40°C,20%~ |
Key attributes-Codewel CW523 High-Performance Resin-Enhanced Wax Thermal Transfer Ribbon
| Applicable Equipment | For Zebra, For Godex, For Sato, For CITIZEN, For TEC, For TSC | Feature | Compatable |
| Type | Printer Ribbon | Model Number | CW523 |
| Brand Name | Codewel | Product Name | Wax Resin Ribbon Thermal Transfer Ribbon 110mm*300m |
| size | Width: 30mm-330mm Length: 70m-900m | Color | black |
| Material | wax,resin | Certifications | RoHS |
| Features | 0.5 inch/1 inch /1.5 inch/Customized | Size | Customizable |
| Ink Side | inside/outside | Packing | Neutral Packing |
| Place of Origin | China |
|
how to choose ribbon
Material:Wax,Wax Resin,Resin
A.How to choose Ribbon Material?
If print on Paper label, normally choose Wax Ribbon;
If pirnt on PP label,or glssoy Paper label,choose Wax Resin Ribbon;
If print on PET,PVC label etc,choose Resin ribbon.
B.Printer and its ribbon?
Normally the printer,decide 3 item info of the ribbon:
a.The maximum width and length of the ribbon;
b.The ribbon ink side:ink out or ink in;
c.Flat head ribbon or near edge ribbon;(Printer head has two kinds:Flat print head and near edge print head,normally is flat head,few is near edge print head)
FAQ
Q1.Are You a Manufacturer?
Yes, we are specilizing in Hot Coding Foil, Thermal Transfer Ribbon
and related to the coding machine over 10 years.
Q2.What Information Shall I provide if I Want to Get Quotation?
-For the hot coding foil: width, length, color, quantity and type.
-For the hot ink roller: outer diameter, height, color, quantity and your
printing temperature.
- For the thermal transfer ribbon: width, length, color, type,ink in or ink
out,quantity etc.
Q3.why choose Codewel?
We have factory and can offer stable quality control, enough stock, fast
shipment.
- Professional R & D team can meet any size and needs.
- Good pre-sales and after-sales service.
- Offer free sample for you to test.
Q4.How do You Deliver the Products?
- By sea (please inform destination port)
- By air (please inform designate international airport name)
- By courier,DHL, FEDEX, TNT, UPS,EMS.Ect.(please offer door to
door delivery address)
Q5.What's the regular lead time for Products?
Common size in stock, within 3 days.
Customized size need about 7-10 days.
